Full Automatic AC Voltage Stabilizer AIR COOLED SERVO MOTOR Three Phase HSJW 15kVA


Download data sheet here

Rated power in VA: 15 kVA

Minimum insulating resistance: 5 MOhm

Maximum [In] rated current: 22.8 A

Efficiency: 92 %

Input voltage limits: 260…430 V

Optional feature: Bypass, Cooling fan

Protection type: Overvoltage for output, Undervoltage protection optional for input, Undervoltage protection optional for output, Overload protection optional, Phase failure optional, Temperature rise protection optional, Time delay optional, Inrush surge protection optional.

Signalling function: Dial pointer indication

Output voltage: 380 V AC +/- 4 %

Network frequency: 50/60 Hz

[Uimp] rated impulse withstand voltage: 1.5 kV per minute

Mounting support: Floor-standing
